SGHA36AT0400 Spectra RMS by General Electric Circuit Breaker Frame

Product Description

SGHA36AT0400 Spectra RMS by General Electric Circuit Breaker Frame

–>

SGHA36AT0400

3P 400A frame 600V Spectra RMS Molded Case Circuit Breakers (SG400) This unit includes a digital, solid state, RMS sensing trip system with field installable, front-mounted rating plugs to establish or change the breaker ampere rating. Adjustable instantaneous with tracking short-time is standard on all frames. The trip unit uses digital sampling to determine the RMS value of sinusoidal and non-sinusoidal currents.

New or Re-certified Available

Warranty Information

`
